What is hypermist system?

What is hypermist system?

The hypermist system is a fire suppression system that is commonly used on board ships. It is designed to quickly extinguish any fires that may occur on the vessel, thereby preventing damage to the ship and potentially saving lives. The system works by using a special mist that is generated by high-pressure water pumps.

hypermist system

How does hypermist system work?

When a fire is detected on board a ship, the hypermist system is activated automatically. The high-pressure water pumps are turned on, and water is pumped through a series of pipes and nozzles to create a mist that is then sprayed over the area where the fire is located. The mist is made up of very fine water droplets that quickly cool the fire and remove heat from the surrounding area. This helps to prevent the fire from spreading and causing further damage.


How is it activated?

There are smoke and flame sensors on the areas where the hypermist system is set to activate. If both of these alarms are triggered together then the hypermist system will turn on automatically. Two different sensors are employed here so that we can be very sure that a fire has occurred before starting the hypermist system so that machines do not get damaged over a false alarm.

hpermist activation

Another way of activating the alarm is to manually trigger the switch if a person notices a fire nearby and the detectors were not able to detect it, then he can manually trigger the system with a switch nearby the machines or from the main control panel.

water mist local pump

Where are these systems employed inside a ship?

These fire fighting systems are placed in rooms with machineries which have a higher chance of catching on fire, such as:

  • Incinerator
  • Main Engine
  • Generators
  • Purifier
  • Boiler

What are the advantages of hypermist system?

The hypermist system is very effective at extinguishing fires quickly, even in areas that are difficult to access. This is because the mist is able to penetrate small spaces and crevices, which means that it can reach fires that may be hidden from view. Additionally, the mist is non-toxic and does not leave any residue, which means that it is safe for both people and equipment.

One of the main advantages of the hypermist system is that it is very reliable. The system is designed to operate automatically, which means that it can respond to fires quickly and without the need for human intervention. Additionally, the system is very easy to maintain, which means that it can be kept in good working order with minimal effort. Overall, the hypermist system is an important component of any ship’s safety systems. It is highly effective at extinguishing fires quickly and preventing them from spreading, which can help to save lives and protect valuable equipment. As a result, it is a system that is widely used across the shipping industry and is considered to be a key part of any ship’s safety equipment.
